Fig. 50. Flashing and Counter-Flashing around a Chinmey. what happens when the girder commences todry out. It will shrink, causing the post aboveto settle, which will affect the part of the build-ing carried in this way. Fig. 52 shows a muchbetter way of framing these posts. The postabove rests… … Fi^. 51. Erroneous Method. Fig. 52. Correct Method.Framing of Posts and Girders to Counteract Effects of Shrinkage. ARCHITECTURAL DRAFTING 279 girder is carried by the steel plate as shown, orby means of a cast-iron post-cap. By this meansthe shrinkage in the girder does not affect the
