Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 342
ARCHITECTURAL DRAFTING 295 … CEMENT ■pXA5TEffnCTAL LATH Fig. 76. Details of Casement Window. 296 ARCHITECTURAL DRAFTING brick wall, although the same detail will applyto a frame wall. In Fig. 71 we have the details and dimen-sions for a double-hung window in a frame wall,the exterior of the wall being plastered. In Fig.72 we…
Architecture · Building
