Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 193
t neces-sarily have its lower edge on the inside of thewindow, so that any water which once entersbetween the lower rail of the sash and the siUwill leak into the room. To prevent the waterfrom entering at this point, an undercut dripis provided on the lower rail of the sash, so thatany water which… … Fig. 93. Casement Window in Cement Plaster House. pose of casting off any water which may bedriven against it in severe weather. The sill is rebated for the outside blinds,and has an apron which is tongued into it. FRAMING 167 The wall is frame, constructed in the usualmanner of two by fom-inch…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
