Fig. 29. Framing for Transom Windows. A Triple Window. A triple window, withtwo side sash casements, while the center sashis stationary, presents an inteiesting problemin window framing. Fig. 30 shows detailed sections through thesills of both the center and side windows. Boththe outside sill and… … FRAIVIING 59 and the casements have an additional sill, asshown, which raises the sash sufficiently to clearthe stool. The writer has used this methodmany times in actual practice, and same hasalways given satisfaction. Framing for Octagon Bay. Another pointin the construction of windows is in bay…
