Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 85

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 85
yS GUIDE AND ASSISTANT 99—Gothic Arch.—The most common Gothic arch isone whose radius is equal to its width, as shown in Fig. … 3 c Fig.l05 106. All Gothic arches are easily struck from the centre,as shown on the plans and drawings. CHAPTER X. Drop Arches—Three-centre Arch—Four-centre Arch—To Draw the Tudor or GothicArch—To Draw the Soffit or Veneering of a Drop or Gothic Arch ivith SplayedJambs — To Lay Out the Soffit or…
