Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 400
d to the flange, Z. The TYPICAL GASOLINE CARRIAGES. 387 conical clutch rim, B, being bolted upon the fly-wheel. The uni-versal coupling, D, connects with the transmission gear, has abushing, B, and runs freely on the motor shaft, S. The collar,F, is keyed to the universal coupling, D, by key, G,…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
