Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 400
Fig. 295.—Internal Cone Clutch of the Peerless Car. A, engine fly-wheel; B,female cone; C, male cone; T>, universal coupling- on male cone; E, bush-ing on D; F, collar keyed on D; G, key; H, ball bearings for taking upthe thrust on disengaging clutch; J, flange on ball cone; K, receptacleon D…
Automobiles
