Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 409

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 409 — the spring, Q, which 396 SELF-PROPELLED VEHICLES. normally presses the spur-driving gear, B, against hub, H, andcauses teeth on the right-hand face of its hub to mesh with simi-lar teeth on H, which is integral with the differential gear case.When teeth on E mesh with those on H, E is locked to the… … Fig. 302—Detail Section of the Pope-Toledo Clutch. The parts are: A, fly-wheel; B, clutch ring; C, clutch ring screw; D, clutch cone; E, clutchleather; F, cmtch bolt; G, clutch bolt nut; H, clutch sleeve; I, clutchsleeve bush; J, clutch spring; K, clutch spring plug; L, clutch springplug nut; M,…

Automobiles
