Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 61

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 61 — With this arrangement, as may be readily understood, anyeffort to change the direction of the travel will cause the arm ofthe outer wheel to approach the right angle with the transversethrough axle bar, and cause the arm of the inner wheel to moveproportionately away from the right angle. Moreover,… … Fig. 48.—Steering Connections of the Panhard Carriages. The spindle of the steeringhand wheel carries a worm gear at its base, which actuates a toothed sector, asshown. This swings an arm and moves the drag-link attached to the arm at the baseof the steering head. The transverse drag-link…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
