Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 639
the pattern of those used in connec-tion with gasoline motors. As shown in an accompanying fig-ure, these gears, mounted on a counter-shaft, may be changedby shifting in the width of the wagon by means of a lever, 5.When this lever is in the position indicated, the low speed gears,M and N, are… … Fig. 460.—The Lifu Compound Steam Engine for heavy vehicle use. This section isdrawn through the centre of the cylindrical steam chests, which, as in the Thorny-croft engine (Fig. 273), are below and at the sides of the steam cylinders. The appear-ance of eccentricity in the attachment of the…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
