Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 172
Fig. 202—The use of blocks in mounting an angle plate to the faceplate for machining method of mounting mil be made very clear by referringto the sketch at Fig. 203. The angle plate should be jzSn r-t^ … Fig. 203—How the bolts are placed for holding the angle plate to the face plate bolted very rigidly with no play whatsoever. The angleplate mounted upon the lathe is shown in Fig. 204. Be- 172 Shop Practice for Home Mechanics fore the turning is started the square should be laid onthe bed of the…
Machine-shop practice · Handicraft
