rilled and tapped tofit the rod. One of these large nuts is made for each endof the rod. After they are put in place on the rod, it milbe seen that by turning them back and forth, an adjust-able rod is obtained. This will enable the mechanic toinsert the rod in its place and adjust it to the proper… … Fig. 222—A four-throw crankshaft turned from the solid judgment in gauging the proper degree to which the nutsshould be adjusted for accurate work. The crankshaft illustrated in Fig. 222 forms rather adifficult piece of lathe turning and the following outlinewill give the reader a very good idea of…
