Hutchinson, G. W. Caldwell, Leighton of Stretton, Frederic Leighton, Baron, 1830-1896 · London ; New York : Macmillan and Co. · leaf 76
from the points m m to meet ad in o o, and from n n tomeet g h and g 112 in l l. Find k on e f, and then draw theupper semicircle through the five points o, L, k, l, o. Next findon the two lines n l the points s s, and on e f the point p. Wehave now five points for the lower semicircle, namely M,… … M B N H2 TO Fig. 33. Draw on the ground line a b the nearest edge of the widthof the block. Find the length of bo; through o draw a verticalline parallel to a b ; on that line find the point c and join b c ;get the height of CD in proportion to a b. Join ad. On theground line find the place of m,…
Drawing
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
