thus inducing currents in thecoils. In one construction shown in the cut the field magnets a, a• ■ are U shaped and are arranged in a circle, their poles pointinginwards. A single exciting coil c, c * * * is wound around the circlein the bend of the U-shaped segments. The poles carry the arma-ture… … Fig. 139. Inductor Dynamo. Dynamo, Interior Pole. A dynamo with a ring armature, withfield magnet pole pieces which extend within the ring. 200 STANDARD ELECTRICAL DICTIONARY. Dynamo, Iron Clad. A dynamo in which the iron of the fieldmagnet is of snch shape as to enclose the field magnet coils as…
