alve to move toward its mid-position. Admission continues until the valve returns to the positionshown in Fig. 8. Here the outside lap just closes the left-hand steamport, cut-off takes place, and the steam already in the cylinder beginsto expand. As the valve continues to move toward the left,… … Pig. 9. Valve Position with Exhaust Port Closed on Crank End dotted position of crank and eccentric in Fig. 10 shows the valvereturned to the point of compression, which continues until the con-ditions of Fig. 6 are again reached and the opening valve allows steamagain to enter the cylinder. 8…
