Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 344
I J^: Zero Line of Pressure … Line of Pressurein Condenser Fig 167. 323 324 THE STEAM-ENGINE AND OTHER HEAT-MOTORS. combined diagrams to the area CNHSK. In Fig. 167 the distanceCN for the high-pressure cylinder is found in the same manner asin the case of the simple engine. . . . The mean effective pressureof the ideal diagram…
Steam-engines · Heat-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
