Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts (1880)
D. Appleton and Company, Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 630
pal dimensions are as follows : Heating surface in furnaces 115 sq. ft. in combustion-chamber 158 in tubes 573.5 Length of boiler 25.46 ft. Diameter of circular shell 5.25 ft. Number of tubes 80 Outside diameter of tubes 3 in. Grate-surface 28.75 sq. ft. Heating surface in external shell.. 173.5… … are shown in Fig. 3501. Numerous other diagrams, similar to those illustrated, were taken duringthe test, and the results obtained from them are appended: ton, reduced to equivalent pressure on pump-piston.. .48.18 lbs. per sq. in. Pressure on low-pressure pis-ton, reduced to equivalentpressure on…
Mechanical engineering -- Dictionaries
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
