type, with brass rubbingrings. (g) The Crosshead. — The three typical forms of this piece are,four-bar or wing crosshead of Fig. 208, the slipper type in Fig. 209,and the block or trunk form in Figs. 210 and 211. The first requiresfour guide bars, two at each side, and is little used; the second… … Fig. 208. — Crosshead from Engine in Fig. 2, of four-bar type. View D showsgrooves in bottom face which are filled with babbitt metal, so that rubbingsurface is partly babbitt, partly cast iron: view E shows how wrist pin is lubri-cated by oil caught from guides. Scale 1 to 10.
