The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 370
Fig. 210. — Crosshead of Block Type, for bored or cylindrical guides, as in Fig. 6,and with adjustable wedge shoes. View E shows inside of shoe, with holes forcap screws; view F shows dovetail grooves for holding babbitt facing. … f € gyp 3
Steam-engines · Steam-turbines
