The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 368
Fig. 210. — Crosshead of Block Type, for bored or cylindrical guides, as in Fig. 6,and with adjustable wedge shoes. View E shows inside of shoe, with holes forcap screws; view F shows dovetail grooves for holding babbitt facing. S^grz t 3 … Fig. 211. — Block Crosshead of the AUigator Form, commonly used in locomo-tives; this to accompany cylinder in Fig. 200. Body and shoes of cast steel;rubbing surfaces faced with tin, which is self-soldered to steel. Scale 1 to 12. 354 WORKING AND CONSTRUCTION OF THE ENGINE. [Chap. VII. it consists…
Steam-engines · Steam-turbines
