The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 364
Fig. 205. — Locomotive Pistons of the Solid-disc Type. Scale 1 to 12. to the shape of the piston surface, and thus keep down the clearancevolume. In Corliss engines, the built-up piston is usual, exemplified in Fig.206. There is first the ribbed body or spider, fast on the rod. The
Steam-engines · Steam-turbines
