Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 103
Fig. 97.—A Belt-Driven Power-Pump. Crank Shaft^Sprocket Wheel Pump% -Crank \ JZII [j je-Zham Motor, … Fig. 98.—A Chain-Driven Power Pump. (2) Duplex power pumps (Fig. 90, 200, and 201) in which thepumping operation is performed by two pistons or plungersoperated by a common crank-shaft, (3) Triplex power pumps Sec. 87] CRANK-ACTION PUMPS 83 (Fig. 93) in which the pumping operation is performed…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
