Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 327
Fig. 303.—Turbine With Westinghouse-Leblanc Surface Condenser. (The equipmentshown has been superseded by more modern designs.) Water-Pistons—-. Pocketed Afc* AirInlet ■Rotating Impeller … Hurling- _ Water Inlet^£JM! M W^5t?f,0nCfri>■f Guide VanesCompression Channel— Fig. 304.—Illustrating Principle Of Alberger Hurling-Water—Centrifugal—AirPump. (As the impeller revolves, it throws streams of water out between its blades.Each time a stream of water passes a compression channel, a…
Steam power plants · Pumping machinery
