t. long. The operating steam-pressure is 185 lb. per sq. in. gage. 374 STEAM POWER PLANT AUXILIARIES [Drv. 11 Solution.—The given rated steam-flow of 30,000 lb. per hr. may,allowing a 50 per cent, excess rating, be reduced to (30,000 -f- 60) X1.50 = 750 lb. per min. The given gage pressure, 185… … £>0 O 00 — ^ K)o o o • • — 4-aaj loaaiouYiH -i2>d Moui zuionbg jza sjounod ui scon sunssaja . O a « r ponding to 750 lb. on the base line (Fig. 357) proceed vertically upwardto B on the line of 200 lb. absolute pressure. Proceed thence downward,parallel to the oblique lines, to C on the line…
