e), and cari-y italong the range to the vanishing-point, fixing the pointswhere the arches cut their diagonals all along. If the arch iscusped, a line should be drawn at f to mark the height of thecusps, and verticals raised at o and h, to determine the intervalbetween them. Any other points may be… … In Fig. 64. the more distant arch only is lettered, as theconstruction of the nearest explains itself more clearly to theeye without letters. The more distant arch shows the gen-eral construction for all aiches seen underneath, as of bridges,cathedral aisles, kc. The rectangle a b c d is first…
