The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 223
the wefts. By these actions the doubled end of the doubleweft is secured, and the weft carrier recedes harmlessly, having beenforced by the stitch of the small needle to allow the weft to remain.At the other side of the loom the same function is simply performedby a small, pointed pin, with a… … Fig. 474.—Weft-retaining Mechanism of Axminster Carpet Loom A, Needle. B, Weft, l, Shuttle, m, Propeller, the two arms ofwhich are linked by a spring T. N, Thread of shuttle, u, Shuttle-race carried on the support v attached to the framing. The shuttleis driven by a cam through the rod w, and the…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
