ch as F(Fig. 29), should always passbelow the centre of the pawlpin. Springs are also used to keep the pawl on the teeth,and so prevent the pawls bouncing out on the return move-ment of the vibrating arm, which they are apt to do if a quickfeed is being given. Example.—A sketch is given in Fig. 30… … Fi<5.29.
