Thermodynamics of the steam-engine and other heat-engines (1889)
Peabody, Cecil Hobart, 1855-1934 · New York, Wiley & Sons · leaf 180
Fig. 32. … 156 THERMODYNAMICS OF THE STEAM-ENGINE. 6TEAM The supply of water is controlled automatically by themovable piston iVTV, which moves freely in the cylindrical shell MMj and is guided also atthe forward end; as shown,it is as far forward as it cango. The impact of the wa-ter upon the piston tends…
