the direct exhaustport K in the seat by means of cavity C in the rotary. Atthe same time chamber D and the equalizing reservoir aircan pass out to the atmosphere through the preliminaryexhaust port E, groove P in the rotary, groove H in theseat and the direct exhaust port K in the seat; this… … Fig. 8. Eelease Position WESTINGHOUSE AIR BRAKE . 199 Operation of the Quick Action Triple RELEASE Fig. 8 is a view of the triple in position for chargingthe auxiliary reservoir and releasing the brake. In charging, the air from the brake pipe enters thetriple from the crossover pipe at the point…
