A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 198

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 198
on D which is used as a pivotat E for the lever F. About half way up the length ofthis lever F is a pin G, which comes under one end ofthe lever H as centred at I, when the lever is movedin, and consequently causes the projecting screw J onthe other end of the lever H to move down and pressagainst… … ously explained in connection with the other splicer. Situated on top of the post A (see again Fig. 2 ofthis article) is the yarn feeding arrangement for theextra yarn and which consists of a specially shapedpiece K, the outer end of which is made with anupwardly projecting arm L for holding one…

Textile fabrics · Textile industry · Textile machinery
