Grant, George B. (George Barnard), 1849-1917 · Boston, Grant gear works, incorporated · leaf 103
-- ^1 I Beale Shew Bevel Gears, Bight Hand Spiral at 45 Fig, 163, Fig, 163a. … Left Hand Spiraliat 45* The working length of each gear is asdetermined by the line L of Fig. 161, andthe whole surface of the tooth within that Approximate Skeiv Teeth. 101 limit will be swept over by the line ofcontact. If the length of each gear is equalto the radius of the other gear it will…
Gearing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
