Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise .. (1916)
Swingle, Calvin F. (Calvin Franklin), b. 1846 · Chicago, F.J. Drake & company · leaf 833
FIG. 5 Hornsby-Akroyd vertical engine. ^ 810/ Steam Engineering … 13 Oil spraying nozzle. 14 Control lever. 15 Hand hole cover. 16 Crankpin brasses. 17 Flywheel. 18 Governor weight. 19 Cam. FIG. 6 Names of Parts. 20 Stud carryinsr governor weight. 21 Crankcase end plate. 22 Wrist pin bushing. 23 Exhaust pipe flange. 24 Speed control segment. 25 Bracket carrying…Steam engineering · Electrical engineering · Steam-turbines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
