Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery (1922)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 1106

An illustration from Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery, 1922, leaf 1106
al circuit is increased or diminished. The arma-ture being kept at a constant speed of rotation^ in a con-stant field of force, by the engine, or other source of power^it v/ill impress upon the circuit a constant voltage. Thisapplies of course to an accurately arranged winding. Over… … FiG. 459 CIECUITS IN A COMPOUND DYNAMO stant voltage is required, not at the generating plant, butin the heart of the district several miles distant. In anover-compounded dynamo the series coil is given a certainnumber of turns in proportion to the turns in the highresistance shunt coil, and the…

Steam engineering · Electrical engineering · Steam-turbines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
