Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 210
FIXED SHOES 193 them together. The shoes are about 5 in. wider than the bot-tom flanges of the girders, to which they are secured by eightvertical bolts. They have three longitudinal webs : the centerone is in the plane of the girder web, and engages the pin witha half-hole bearing. The pedestal is…
Bridges
