Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 59

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 59 — scribe the arcs 0 P andQ R, ending at the points 0 and Q on the edge of the strap. From thepoints 0 and Q scribe arcs intersecting at the point 8 on the edge of thestrap. With the chisel make a mark on the strap at S. Bring the eccen-tric around so that the point F corresponds with the point ;S^,… … FIG. 52. driven by one eccentric. Also assume that the builders have made allproportions, lap, width of ports, and bridges correct. Take out the cut-offvalve and start to adjust the action of the main valve, bearing in mind itshould be set practically the same as any D slide valve. THE RIDING…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
