The microscopy of vegetable foods, with special reference to the detection of adulteration and the diagnosis of mixtures (1916)
Winton, Andrew Lincoln, 1864-1946, Moeller, Josef, 1848-1924, Winton, Kate Grace Barber, Mrs · New York, John Wiley & sons, inc.; [etc., etc.] · leaf 409
Fig. 299. Fig (FicusCarica). Epi-carp in surface view, h hairs andhair scars. Xi6o. (Moeller.) 388 FRUIT. solution are suspended in the milky contents. On warming, the latexcoagulates, forming large drops. The fibro-vascular bundles occurringin the middle layer have small spiral or reticulated… … K— Fig, 300. Fig. Longitudinal section of fruit flesh showing p parenchyma, K cr>Stals, mlatex tubes and g vessels. X160. (Moeller.) easily found in the ripe fruit. Hairs occur on this as well as on tlieouter epidermis. Pericarp (Fig, 301), The inner surface of the receptacle is thicklybeset…
