Wiring diagrams of electrical apparatus and installations (1913)
McGraw-Hill · New York, McGraw-Hill Book Company · leaf 159
Fig. 235.—Typical series-motor starter with no-load release across the line. … Fig. 236.—Typical shunt or compound motor starter with no-load release in series withthe shunt field winding, and an overload release in series with the armature. The series wind-ing for a compound motor is shown dotted, connected between the points a and b, instead ofthe solid hne. If the current…
Electric wiring
