Yarn and cloth making; an economic study; a college and normal schools text preliminary to fabric study, and a reference for teachers of industrial history and art in secondary and elementary schools (1918)

Kissell, Mary Lois · New York, The Macmillian company · leaf 254

An illustration from Yarn and cloth making; an economic study; a college and normal schools text preliminary to fabric study, and a reference for teachers of industrial history and art in secondary and elementary schools, 1918, leaf 254
th them beyond the griff (G). This allows the grifi to riseand carry up the remaining hooks which raise the heddles. WEAVING TYPES shedding apparatusplaced on topof loom totake theplace of thedrawboy andpulley-box(24,26e,f,g).(i) shaft-heddles.(2) string-heddles.endless chainof… … A Fig. 85.— The JacquardAT Work Action of horizontal needleon vertical hook when itis pushed back by patterncard. The needle carriesthe hook off the griff. 196 YARN AND CLOTH MAKING leash, or leash strings with mails and lingoes. comber board.Power — Hand and Foot (31, 31a).Process — Shedding. 1.…

Textile industry · Spinning · Weaving
