Yarn and cloth making; an economic study; a college and normal schools text preliminary to fabric study, and a reference for teachers of industrial history and art in secondary and elementary schools (1918)
Kissell, Mary Lois · New York, The Macmillian company · leaf 261
rking Parts of Power Loom Left, doth beam, breast beam. Center, reed-batten oscillating from below;four shaft-heddles two down two up opening shed. Right, warp beam. 4-5- 6. 7- bobbin-shuttle thrown by levers (27, 27d, e, f).batten with shuttle-race, shuttle-boxes andpickers is swung from below… … Fig. 89.—• RobertsLoom, Side Elevation, 1830The warp passes from warp beam (/), over roller (K), through heddles (L),through reed of batten (H); here the cloth continues over breast beam andis rolled upon cloth beam (A). WEAVING TYPES 203 Wefting. Shedding, Picking, Battening. These processes…
Textile industry · Spinning · Weaving
