C; join ACT, D MP andC MP, cutting A C.Y. in F and E. On AB describe squareASMB; join S C.Y., M C.Y. and B C.Y.; through E and Fdraw parallels to AS, meeting S C.Y. in H and G; throughG, H draw parallels to SM, meeting M C.Y. in K and L.Draw ~LN from L _J_ to MB, and EX from E parallel to AB.This… … The plinth differs froma cube only in the rela-tion of its dimensions;the principle employedin drawing them is thesame, but a particularside of the plinth is men-tioned in reference tothe P.P. or G.P. In thecube this is quite un-necessary, as all the sidesare equal. Example 1.—Draw aplinth whose…
