Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 573
Fig. 1320. … tise and tenon are omitted, and the girts supplied bya board a 3 or ^ X 1 let into the studs (Fig. 1318)and firmly nailed to them. The studs are nailed tothe plates and sills. The studs at all door-openings should be set atleast 2 wider and 3* higher than the size of the fin-ished opening. It is…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
