Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 74
s cut away between theinlet and outlet to give room for the vibration of a par-tition piece which is hinged at one end, and which bearsagainst the circumference of the eccentric at the other COOLmo SYSTEMS 47 end. In operation, the eccentric working with the par-tition piece displaces a quantity of… … Fig. 16.—The Locomobile cooling system. The cooUng water is circu-lated by a centrifugal pump which draws the water from the bottom of theradiator and forces it upward to the cylinders, whence through vertical standpipes it is carried clear to the bottom of the water jackets, thus insuring…
