Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 290
Connecting Rod- Connecting Rod Bearing, Bearing LinersConnecting Rod Cap Connecting Rod Bolts … Oil Scoop Fig. 118.—Typical Piston and Connecting Rod Assembly. vided at the top of the piston and one may consider itas two pistons in one. One of the important conditions in piston design isthe method of securing the wrist pin which is used to 292 Aviation Engines connect the piston to the upper…
