Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 462
ethrow crank-shaft with crank-pins separated by 180 de-grees, a six-cylinder radial engine is produced which runs Anzani Aviation Engines 463 very quietly and furnishes a steady output of power.The peculiarity of the construction of this engine is inthe method of grouping the connecting rod about… … Connecting-Rods. Crank-Shaft Crank Case-- K ExhaustValve Cylinder Flywheel Fig. 192.—Sectional View of Anzani Six-Cylinder Water-Cooled Aviation Engine. connecting rod big end with a shoe which consists of aportion of a hollow cylinder held against the crank-pinby split clamping rings. The…
Airplanes
