Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 86
is compressing, cyl-inder No. 2 is exhausting. During the time that the chargein cylinder No. 1 is exploded, cylinder No. 2 is being filledwith fresh_gas. While the exhaust gases are being dis-charged from cylinder No. 1, cylinder No. 2 is compressingthe gas previously taken. The same condition… … M M /tMa U VI Ttco Cylinder VerticalCranhpins on Same Platte
Airplanes
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
