Building construction and superintendence, by F.E. Kidder ... (1896)
Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, W.T. Comstock · leaf 150
Fig. 177. VAULTED CEILINGS. 141 … Fig. 178. For light walls, it would be better and safer to useornamental tie-beams in place of the hammer beams,and an ornamental king post, as in the roof of Trin-ity Church, Boston [see Fig. 182]. A flat vaulted ceiling, with a contour about as indicated by thedotted line in Fig. 156, can readily…
