atform, the coal being shovelled into the pocketsfrom cars on a track immediateW back of the pockets. This system gives as quick dispatch in coal-ing engines as a high-chute system. Where quick delivery is required and space for a long incline isnot available, this style of coaling platform ofters… … Fig. 276.—Cross-section. Coaling Platform, St. Louis, Iron Mountain i5r» Southern Railway.—The coaling-platform design ofthe St. Louis, Iron Mountain & Southern Railway, shown in tig. 276, consists of a platform, 12 ft. 4in.above the top of rail, with a supply-track at thecentre of the…
