d to g on the other side; ex-tend the jack h, and all the jacks on thatside, to the line df, for the length and topbevels; extend the jack, a, and all on thatside, to the line d g, for the length and bevelson that side of the hip. The down bevelsof the jacks will be the same as that of thecommon… … 6. The valley-roof is the same as the hip-roof inverted. The principle of constructionis the same, with a little different applica-tion. HAND-BOOK. 13
