Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 205
larged detailthrough b b (Fig. 666), showing the jointbetween the frame and the stile of the case-ments, also of the boarding nailed to the 184 CARPENTRY AND JOINERY. frame and covered with lead or zinc. Afterthis boarding has been fixed, the mouldingg is attached as shown. The dimensionsshown of… … Fig. 676.—General View of Complete Framing of Bay Dormer Window. be regarded as suggestive rather than abso-lute. Small Dormer Window in MansardRoot. The bare framework of a small dormer surface of this is hollowed out of the solidstone, and afterwards lead is dressed in soas to form the gutter…
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
