King, Charles A. (Charles Albert), b. 1865 · New York, Cincinnati [etc.] American book company · leaf 39
Fig. 19. moktised Drawbored. Joint, … Fig. 20. — Full Frame House. a, aill; &, corner post; c, brace; d, stud; e, head; /.stool; (?, plate; A, floor joists; k,common rafters; m, jack rafters ; n, hip rafters; o, double studs; p, mortised joint; r, openmortised joint; s, mortised joint, drawbored; t, end of rafters for box cornice;…
Carpentry
